Compare our force gauges
Our force gauges |
||||
| Compare our force gauges and choose the force measuring instrument which fits your testing needs. From the Centor First with peak force to the Centor Star Touch with automated calculations and USB output, we have the force gauge for your testing requirement. | ||||
|
|
|
||
| FEATURES | FISRT | EASY | STAR TOUCH | |
| Sensors available | 20lb, 50lb, 100lb | 2lb, 5lb, 10lb, 20lb, 50lb, 100lb, 200 lb | 1lb, 2lb, 5lb, 10lb, 20lb, 50lb, 100lb, 200 lb | |
| Accuracy | 0.25 % FS | 0.1 % FS | 0.1 % FS | |
| Resolution | 1/1,000 FS | 1/10,000 FS | 1/10,000 FS | |
| Sampling rate | 1,000 Hz | 1,000 Hz | 5,000 Hz | |
| Overload protection | 200% FS | 200% FS | 200% FS | |
| Units | N, Lb, Kg | N, Lb, Kg, Oz, g | N, Lb, Kg, Oz, g | |
| Auto-off | 15 min | 5 to 15 min | 5 to 60 min | |
| Bargraph |  |
|
|
|
| Peak in tension and compression | |
|
|
|
| Use of a foot pedal | |
|
||
| Tare | |
|
|
|
| Reversible display | 180° | 180° | 90°, 180° | |
| Battery operated | |
|
|
|
| 8 hours operations without recharging | |
|
|
|
| Fast charge | |
|
|
|
| Low battery indicator | |
|
|
|
| Metal casing and protective elastomer mould | |
|
|
|
| Threaded fixed holes for use on test stand | |
|
|
|
| RS232 output | Max, Min, Current | Max, Min, Current | ||
| Output sampling rate | 50 / sec | 1,000 / sec | ||
| USB output | |
|||
| Digilatic output | |
|||
| Analog output | +/- 1V | +/-1.25V | ||
| Display peak and current value in the same time | |
|
||
| Setup protection | |
|
||
| Backlight display | Black and white | Touchscreen color | ||
| Adjustable set point | |
|
||
| Memory | |
|
||
| Statistics (average, standard deviation) | 100 results | 2,000 results | ||
| Memory card reader compatible | |
|||
| Display force vs time curve | |
|||
| Maxima in a time window calculation | |
|||
| Time necessary to reach maximum force | |
|||
| Average force over the test | |
|||
| Force at time T | |
|||
| Break point | |
|||
| Derivative | |
|||
| First peak | |
|||
| Force on closing contact | |
|||
| Average force | |
|||
| Download curve to a computer | |
|||
