How to check crimp terminals on cables:
A good crimping of a terminal on a cable increases the usable life time of the connection and avoids micro cuts when using the cable in a car or an aircraft.
When do you check wire terminal crimps ?
During the manufacturing cycle and at each change of processing settings, including:
- Checking the first batch manufactured
- Check for each new setup of machines or crimping pliers (tool exchange)
- Check each coil change (if terminals are supplied in a coil)
- Interim checks (every 1000 crimps for example)
- Check the final crimp
Read more
|
Technology focus |
Carousel for tensile tests on terminals
 Our accessory carousel is designed for maintaining crimp terminals during quality tensile tests to determine the break force of crimps.
It can be used with all types of crimp terminals (spade lugs, lugs round spades, spades flags) but also for crimp pins or crimp sleeves fitted to the beams and electrical harnesses.
With its 15 slots with various openings, the operator may test the cable with a size between AWG24 to AWG14 without changing the holding accessory.
.
Read more |
They use our testers |
| ITW, Coach and Equipment, Delphi, Siemens, Motorola, Phelps Dodge, New York Wire, ASA (Atlantic Southeast Airlines), General Cables |
|
Sales |
Wiretest 2 - Automatic wire terminals tester - 500 lb
The test stand Wiretest 2 is designed to verify the quality of crimping terminals. Indeed the success of a good crimp is related to the quality of crimping clamps and proper adjustment of crimping machine.Constant speed as aeronautics and automotive standards required.
Special end of the year : $7999 only
Contact
Technical Specification |
Wire testing solutions |
Wiretest T1-Manual wire terminals tester - 200 lb
 Ideal for small sections of cable, this system WIRETEST T1 measures the tensile strength of crimps on cables up to 100 lb. With its lever arm, it can control easily and quickly crimping terminals during the manufacturing process. The force gauge can be set to beep when the necessary force is reached.
+ info
Wiretest 3F-Motorized tester - 2000 lb
The test stand Wiretest 3 is designed to verify the quality of crimping terminals on cables up to 2000lb. It is used for power cables, power beams and large terminals.
+ info
Wiretest 1 - Small terminals tester - 100 lbThe manual test stand Wiretest 1 allows control of crimps easily in production or in quality. Ideal for cables up to 0.15 sqin, it is designed to hold any type and size of contacts without changing tools with its carousel
+ info
